Cold Isostatic Pressing
是一种在超高压状态下的粉末成型设备，通常用橡胶或塑料作模具包套材料，以液体为传压介质，对粉末坯料在各个方向施加相同压力，压制成预定形状，为下一步烧结、热等静压等工艺提供坯料。
由于能使粉末原料获得高密度、**的材料均质性的制品，而被**地应用于硬质合金、粉末冶金、高速钢、钛及钛合金、耐火材料、石墨、坩埚、陶瓷、稀土永磁、晶体、医药食品等行业的**领域。Cold isostatic press制品非常利于机械加工，还可以生产各种形状特别复杂的制品。
Cold isostatic press标准规格一览表
Model | Cylinder inner diameter（mm） | The cylinder is high(mm) | Boost Time（min） | 电机功率 | **压力(Mpa) |
CIP200 | 200 | 300-3500 | 3-10 | 25 | 0-600 |
CIP300 | 300 | 4-10 | 40 | ||
CIP400 | 400 | 500-3500 | 6-20 | 45 | 0-400 |
CIP500 | 500 | 8-20 | 55 | ||
CIP600 | 600 | 10-20 | 55 | ||
CIP700 | 700 | 10-20 | 75 | ||
CIP800 | 800 | 1000-3000 | 3-10 | 100 | 0-300 |
CIP900 | 900 | 3-10 | 120 | ||
CIP1000 | 1000 | 3-10 | 120 | ||
CIP1250 | 1250 | 1500-3500 | 18-20 | 150 | 0-200 |
CIP1500 | 1500 | 18-25 | 175 | ||
CIP1650 | 1650 | 1500-3500 | 20-25 | 175 | 0-200 |
CIP1850 | 1850 | 25-30 | 250 | ||
CIP2150 | 2150 | 25-30 | 275 |
可订制其他不同规格的产品，**缸径可达2.5米，如需双介质加塑胶隔离套，有效缸径及height有相应缩减。
Cold isostatic press
Cold isostatic press
Cold Isostatic Pressing
It is a kind of powder molding equipment in the state of ultra-high pressure, usually using rubber or plastic as the mold covering material, using liquid as the pressure transfer medium, applying the same pressure to the powder billet in all directions, pressing it into a predetermined shape, and providing billet for the next step of sintering, hot isostatic pressing and other processes.
Because it can make powder raw materials obtain high-density and material homogeneity, they are used in cemented carbide, powder metallurgy, high-speed steel, titanium and titanium alloys, refractory materials, graphite, crucibles, ceramics, rare earth permanent magnets, crystals, medicine and food and other industries. Cold isostatic press products are very good for machining and can also produce a wide range of products with particularly complex shapes.
Cold isostatic press标准规格一览表
Model | Cylinder inner diameter（mm） | The cylinder is high(mm) | Boost Time（min） | 电机功率 | **压力(Mpa) |
CIP200 | 200 | 300-3500 | 3-10 | 25 | 0-600 |
CIP300 | 300 | 4-10 | 40 | ||
CIP400 | 400 | 500-3500 | 6-20 | 45 | 0-400 |
CIP500 | 500 | 8-20 | 55 | ||
CIP600 | 600 | 10-20 | 55 | ||
CIP700 | 700 | 10-20 | 75 | ||
CIP800 | 800 | 1000-3000 | 3-10 | 100 | 0-300 |
CIP900 | 900 | 3-10 | 120 | ||
CIP1000 | 1000 | 3-10 | 120 | ||
CIP1250 | 1250 | 1500-3500 | 18-20 | 150 | 0-200 |
CIP1500 | 1500 | 18-25 | 175 | ||
CIP1650 | 1650 | 1500-3500 | 20-25 | 175 | 0-200 |
CIP1850 | 1850 | 25-30 | 250 | ||
CIP2150 | 2150 | 25-30 | 275 |
Other products of different specifications can be customized, the cylinder bore can reach 2.5 meters, if you need double media plus plastic isolation sleeve, the effective cylinder bore and height will be reduced accordingly.
