Structural composition of isostatic presses
Isostatic press can be divided into: cold isostatic press, warm isostatic press, hot isostatic press and dry bag isostatic press. The composition of its structure is basically composed of the following parts.
2023-08-01 14:40:37Wang Xuemei218
The composition of the isostatic press structure is basically composed of the following parts:
1. Host system
The main unit is mainly composed of: prestressed frame, working vessel under ultra-high pressure pressure, upper cover lifting mechanism, exhaust valve, installation base plate, etc；
2. Boosting system
It is composed of a booster cylinder, a refill tank, a high-pressure tubing and a power system of ultra-high pressure relief valve, check valve and booster cylinder；
3. Hydraulic transmission
The hydraulic transmission part is the device that powers the action of the four executive parts of the main unit.
The hydraulic system is mainly composed of motors, vane pumps, piston pumps and corresponding hydraulic valves and pipe fittings.
4. Electrical control
The electrical control part is mainly composed of programmable controllers; Lifting the upper and lower limit stroke switches of the cylinder；
Push and pull the push and pull of the cylinder to enter and retreat the limit stroke switch；
It is composed of electrical components such as the upper and lower pressure transmitters of the booster cylinder
